X11 knows the data type “cardinal”. For example, the window property
_NET_WM_ICON
(which holds image data for icons) is an array of “cardinal”. I am already not really familiar with that word and I’m assuming that it comes from mathematics:https://en.wikipedia.org/wiki/Cardinal_number
(It could also be a bird, but probably not: https://en.wikipedia.org/wiki/Cardinalidae)
We would probably call this an “integer” today.
EWMH says that icons are arrays of cardinals and that they’re 32-bit numbers:
https://specifications.freedesktop.org/wm-spec/latest-single/#id-1.6.13
So it’s something like
0x11223344
with 0x11
being the alpha channel, 0x22
is red, and so on.You would assume that, when you retrieve such an array from the X11 server, you’d get an array of
uint32_t
, right?Nope.
Xlib is so old, they use
char
for 8-bit stuff, short int
for 16-bit, and long int
for 32-bit:https://x.org/releases/current/doc/libX11/libX11/libX11.html#Obtaining_and_Changing_Window_Properties
That is congruent with the general C data types, so it *does* make sense:
https://en.wikipedia.org/wiki/C_data_types
Now the funny thing is, on modern
x86_64
, the type long int
is actually 64 bits wide.The result is that every pixel in a Pixmap, for example, is twice as large in memory as it would need to be. Just because Xlib uses
long int
, because uint32_t
didn’t exist, yet.And this is something that I wouldn’t know how to fix without breaking clients.
